Brand: MERCUSYS
  • Five 10/100Mbps auto-negotiation RJ45 ports with auto MDI/MDIX supported
  • Easily wired network expansion
  • Compact design for flexible arrangement
  • Plug and play setup, no configuration required
Product SKU: MCS-MS105
Availability: In Stock
Qty:     - OR -   Add to Wish List
Add to Compare

5-Port 10/100Mbps Desktop Switch

MS105

Specifications
Dimensions (W X D X H) 82 x 49 x 21 mm
External Power Supply External power adapter
  (Output: 5.0VDC/0.6A)
Interfaces 5 10/100Mbps ports, auto-negotiation, auto-MDI/MDIX
Standards and Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3x
  CSMA/CD
Fan Quantity Fanless
Data Rates 10/100Mbps at half duplex
  20/200Mbps at full duplex
Buffer Capacity 768Kb
Jumbo Frame 2KB
Switching Capacity 1Gbps
LED Ethernet (1, 2, 3, 4, 5), Power
Transfer Method Store and forward
Certifications CE, RoHS
Package Contents 5-Port 10/100Mbps Desktop Switch
  MS105
  Power adapter
  Quick installation guide
Environment Operating temperature: 0°C~40°C (32°F~104°F)
  Storage temperature: -40°C~70°C (-40°F~158°F)
  Operating humidity: 10% ~ 90% non-condensing
  Storage humidity: 5%~90% non-condensing
